The materials in the raw material warehouse enter into the mixing hopper through the screw conveyor pump, and then are measured and lifted into the mixing bin by the bucket elevator.
After falling into the two-axis weightless mixer for uniform mixing,the materials are put into the finished product warehouse for bag-type packaging by the automatic packaging machine.
Batching: Through screw conveyor, convey materials to weighing batching bin for weighing and batching.
Lifting: After batching all materials, they will be lifted into premixed bin by bucket elevator.
Mixing: The materials in premixed bin fall down into twin shaft mixer through the discharge port for mixing.
Weighing and packing: Well mixed dry mortar falling into finished product bin will be discharged into weighing and packing machine.
Efficient control system, safe and reliable, can be customized according to the customer site
High quality delivery system, low failure rate
Efficient hybrid system
High precision packaging system
Accurate metering system
Dust removal system, small dust, effectively protect the working environment of workers.
| MODEL | RDM-1015 | RDM-1520 | RDM2040 | RDM-4060 | RDM6080 | RDM-80120 |
| CAPACITY(T/H) | 10-15 | 15-20 | 20-40 | 40-60 | 60-80 | 80-120 |
| HOST MOTOR(kw) | 18.5 | 22 | 22 | 45 | 55 | 55 |
| AGGREGATE SIZE(mm) | 0〜4.75 | 0〜4.75 | 0〜4.75 | 0〜4.75 | 0〜4.75 | 0〜4.75 |
| AGGREGATE SCALE(kg) | （200〜1000）±1％ | （200〜1500）±1％ | （200〜2000）±1％ | （400〜3000）±1％ | （400〜4000）±1％ | （500-6000）±1％ |
| CEMENT SCALE(kg） | （100〜600）±1％ | （100〜700）±1％ | （100〜800）±1％ | （200〜1300）±1％ | （200〜1800）±1％ | （200〜2000）±1％ |
| ADDITIVE SCALE(kg) | （5〜30）±0.5％ | （10〜40）±1％ | （10〜50）±0.5％ | （10〜200）±0.5％ | （10〜200）±0.5％ | （10〜200）±0.5％ |
