NE series Bucket elevator is one of the most widely used vertical conveying equipment. Which is suitable for powder and granular material (such as limestone, cement clinker, plaster power, coal) vertical transport. Also, NE series bucket elevator adopts high strength plate chain, which is especially suitable for high grinding and high temperature material (such as cement clinker, ash), the temperature of material is up to 250 degree.
1.Large capacity, from 15 – 800m3/h.
2. Max. height: 50 meters.
3. Introduced high strength plate chain, bucket elevator can transport 250 degree high temperature material.
4. Easy installation and maintenance.
Large transmission capacity. Elevate the capacity up to 15-800 cubic meters / hour.
Low energy consumption. This machine used for the flowing feed method, Gravity induced discharging the material. And use the Intensive large capacity hopper conveyor.
Low chain speed, but big transmission capacity, nearly no material flow back, so small drive power, Theoretical calculation Shaft power is 25%-45% for the Cycle chain elevator.
Long use life. This kind of elevator used for the flowing feed method, between the material and hit, during the feed and elevating, seldom material will flow back, so this Prevent abrasive cost. Strength wear-resistant chain enlarge the use life of the chain and hopper. Actual use shows that: transport chain use life more than 5 years.
Lifting height high. with low speed of the chain speed, stable working, and used the strength wear-resistant chain, so the lifting height is higher.
Good sealing, reduce environmental pollution.
